Kitlock Nano90 Furniture Lock

Sorry this product has been discontinued – click on the link to alternative products

SKU: KIT/NANO90 Categories: ,


Kitlock Nano90 Furniture Lock

Smart thinking. NANO has arrived. Little lockers, doors and drawers will love NANO90.

NANO90 is the ideal keyless solution to upgrade and replace locks on lockers, cupboard doors and drawers. Fit the product in place of standard cam locks, NANO90 can be surface mounted or flush fitted for a really sleek look. Whether installed on lockers, mail boxes, courier drop boxes or medical cabinets, just simply enter a four digit code, lock and go!

Key Features

  • 12 button keypad
  • 8 digit Master and Sub-Master Code
  • 4 digit User Code
  • 6 digit Technician Code
  • Left hand and right hand versions available
  • Up to 100,000 operations from 1 x coin cell battery (supplied)
  • Suitable for doors up to 400 x 400mm
  • Battery override
  • Auto unlock feature
  • All parts / fixings / templates included


Private Function
This is the default function and is already pre-programmed in new locks. This function is used where the same code will be repeatedly used, e.g. an employee with the same locker/drawer in the workplace.

Public Function
In this function the KitLock operates with a single User Code. The user enters a personal four digit code, this locks the lock. The same code is entered once only to open the lock before automatically being erased and ready for the next user. This function is used for short term, multiple occupancy applications, e.g. hot desking in an office or a locker in a sports club.




  • Average Battery Life:  Up to 100,000 operations per 1 x coin cell battery
  • Battery Override:  A 9 volt PP3 battery can be placed against external contacts
  • Buttons: 2 x 6
  • Code Change Method:  Keypad (On Door)
  • Countdown Time Open after X hours
  • Finish Silver:  Grey, Black
  • Function:  Private, Public
  • Keypad12 individual buttons
  • Latch Type:  Cam
  • Lock Material:  Plastic
  • Low Battery Warning:  Red LED will flash on opening to indicate low battery
  • Memory:  Non-volatile memory will be retained
  • Operations:  Up to 100,000 opening per 1 x coin cell battery
  • Orientation:  Vertical, Left Handed, Right Handed
  • Power1x CR2450N
  • Suitable For:  Internal
  • User Levels:  Master, Sub Master, Technician, Standard User
  • User Types:  Code


Anti-Bacterial Coating

Clean by KitLock features an ISO certified* photocatalytic coating which, when applied to our locks, offers enhanced protection against viruses, bacteria, germs and other environmental toxins. The coating utilises a process called photocatalytic oxidation, which means that the coating converts harmful bacteria and germs into a non-toxic compound, resulting in a clean and hygienic surface. The clear coating combats SARS-CoV-2 coronavirus (COVID-19) and can reduce bacterial growth by 99.96%*, providing an additional measure of protection over sanitisation.

Application lead time 7 to 10 working days.

*Codelocks and KitLocks electronic locks offer a two year guarantee and will be repaired, serviced or replaced free of charge if they develop a manufacturing fault. Faults caused by misuse, abuse and/or poor fitting are not covered by the guarantees

For expert advice please contact our sales team.


Bulk Buy Offers

QuantityPrice Per Lock
1 - 24£31.95
25 - 49£30.95

Delivery Info

Lead Time: 5 working days - subject to stock avaialabliy Large orders may take a little longer, please call for more details Delivery Charge: £12.50 to UK mainland. All Other areas please contact for a price
